Includes your choice of pump head for required flow rate.
- Control Type: Digital Variable Speed
- Speed: Variable
- Speed Control: ±2% (1-turn speed control)
- Number of Channels: 1
- Max Flow Rate: 2900 mL/min
- Min Flow Rate: 0.034 mL/min
- Max Flow Rate Per Channel: 2900 mL/min
- Min Flow Rate Per Channel: 0.034 mL/min
- Housing Material: Polyphenylene Sulfide (PPS)
- Tubing Retention: Automatic
- Occlusion: Fixed
- Optimum RPM Range: 0.02 to 600 rpm
- Rollers: Four; cold-rolled steel
- Rotor Material: Cold-rolled Steel
- Suction Lift: 29 ft (8.8 m)
- Gear Ratio: 1:1
- Tubing sizes accepted: L/S 15, L/S 24, L/S 35, L/S 36
- Volume Per Revolution With L/S 15 Tubing: 1.7 mL
- Volume Per Revolution With L/S 24 Tubing: 2.8 mL
- Volume Per Revolution With L/S 35 Tubing: 3.8 mL
- Volume Per Revolution With L/S 36 Tubing: 4.8 mL
- Reversible Motor: Yes
- No. of Pump Heads Accepted: 2
- Type of Pump Heads Accepted: Standard, Easy-Load, Easy-Load II, Quick Load, High Performance, Cartridge, Multichannel, PTFE Tubing, PTFE Diaphragm
- Motor (watts): 75
- Motor hp: 1/10
- Drive IP rating: IP 23
- Electrical: 115 VAC, 1.5A
- Dimensions: 7" W x 7" H x 14.75" D (17.8 cm x 17.8 cm x 37.4 cm)
- Weight: 11 lbs (5 kg)
Click Here For Manual
